108mm Aluminum Lr Elbow

,Aluminum Elbow Stock List,EN755 DIN2605 Aluminum Elbow

Home > Products > Butt Weld Pipe Fitting > Pipe Elbow/Bend > 108 x 4 lr EN755 AW6060 elbow

108 x 4 lr EN755 AW6060 elbow

Share to:
    Payment Type: L/C,T/T,Paypal,Money Gram,Western Union
    Incoterm: FOB,CFR,CIF,FCA,CPT
    Min. Order: 10 Bag/Bags
    Delivery Time: 15 Days

Basic Info

Model No.: BD-L Aluminum elbow

Connection: Welding

Shape: Equal

Head Code: Round

Angle: 90 Degree

Wall Thickness: STD

Material: Stainless Steel

Technics: Pushing

Certification: ASME, ANSI, DIN, BS, GB, API

Color: Silver

Size: 48 X 4

Grade: EN AW 6060 T66

Radius: 1.5D

Additional Info

Packaging: Wooden Case or Pallet or as per buyer's requirements

Productivity: 1000pcs/month

Brand: Bangdong

Transportation: Ocean,Land,Air,Train/DHL/TNT

Place of Origin: Cangzhou,China

Supply Ability: 1000pcs/month

Certificate: ISO/CE/API

HS Code: 73079300

Port: Tianjin Port,Beijing Air Port,Shanghai Port

Product Description



Bangdong have good stock of LR aluminum elbow , like 108 x 4 lr EN755 AW6060 elbow , EN755 DIN2605 aluminum elbow , Aluminum Pipe Fitting elbow stock , EN755 Pipe Fitting Elbow , AW 6060 T66 Sr Elbow , 108mm aluminum LR Elbow . These batch elbow exported to our Russian client every 4 months .


Aluminium piping with a raw, T6060 finish. 3 millimeter wall thickness makes it suitable for welding and constructing own applications. The pipe would benefit from either being polished or painted after the welds have been completed. All in order to prevent the pipe aluminum from oxidizing. To ensure your hose from not popping off, making a nice and secure rounding, a hose joiner can be cut in half and welded on. Fitting hose joiners for the desired pipe is found during Accessories by each article. Very high quality!

These bends have a very narrow center radius, making them very suitable for tight spaces.

DN40 LR Aluminum elbow T66 . Elbow, Aluminium acc. to EN 755, EN AW 6060-T66, sim. to DIN 2605


Photo aluminum elbow Dimension : 108 x 4 mm

48 x 4 mm

89 x 6 mm

Radius : LR aluminum elbow / SR aluminum elbow

Standard : DIN 2605

Material Standard : EN 755 EN AW 6060 T66

End : butt weld bevel end

Elbow, Aluminium acc. to EN 755, EN AW 6060-T66, sim. to DIN 2605

Product description:

Bangdong Pipeline can offer Aluminium ENAW-6060 Pipes, Pipe Fittings & Flanges(6060 - T6), Aluminium 6060 Pipe, Aluminium 6060 Butt Weld Pipe Fitting, Al Alloy 6060 Flanges, Aluminum 6060 - T6 Seamless Pipe, 6060 – T6 Aluminium Alloy butt weld pipe fitting, Al 6060 Flanges, Al 6060 Pipes.

Size Specifications for Aluminium ENAW-6060 Pipes, butt weld pipe fitting & Flanges (6060 - T6): 25mm to 150mm
The alloy composition of aluminium 6060:
Aluminium: 97.9 to 99.3%

Chromium: 0.05% max

Copper: 0.1% max

Iron: 0.1 to 0.3%

Magnesium: 0.35 to 0.6%

Manganese: 0.10%

Silicon: 0.3 to 0.6%

Titanium: 0.1% max

Zinc: 0.15% max

Residuals: 0.15% max

The alloy and its various tempers are covered by the following standards:

ASTM B 221: Standard Specification for Aluminum and Aluminum-Alloy Extruded Bars, Rods, Wire, Profiles, and Tube

EN 573-3: Aluminium and aluminium alloys. Chemical composition and form of wrought products. Chemical composition and form of products

EN 754-2: Aluminium and aluminium alloys. Cold drawn rod/bar and Tube. Mechanical properties

EN 755-2: Aluminium and aluminium alloys. Extruded rod/bar, tube and profiles. Mechanical properties

ISO 6361: Wrought Aluminium and Aluminium Alloy Sheets, Strips and Plates

Applications of Aluminium ENAW-6060 Pipes, butt weld pipe fitting & Flanges (6060 - T6): Extrusions with complex cross sections and/or requiring anodising, Architectural sections for windows, doors, curtain walls, Interior fittings, frame systems, lighting, ladders, railings, fences, Heat sink sections, electronic modules, electro motor housings, Flexible assembly systems, special machinery elements, Truck and trailer flooring, pneumatic installation, railway, inside applications, Irrigation, heating and cooling pipes, Furniture, office equipment.

From Bangdong Pipeline client can avail Aluminium ENAW-6060 Pipes, butt weld pipe fitting & Flanges (6060 - T6), Aluminium 6060 Pipe, Aluminium 6060 butt weld pipe fitting, Al Alloy 6060 Flanges, Aluminum 6060 - T6 Seamless Pipe, 6060 – T6 Aluminium Alloy butt weld pipe fitting, Al 6060 Flanges, Al 6060 Pipes.
Client can procure smaller quantities of 6060 Aluminium Alloy Pipe, butt weld pipe fitting & Flanges online ready stock from us at premium cost in any destination by just sending us an email.

If any requirements for Aluminium ENAW-6060 Pipes, butt weld pipe fitting & Flanges (6060 - T6), Aluminium 6060 Pipe, Aluminium 6060 butt weld pipe fitting, Al Alloy 6060 Flanges, Aluminum 6060 - T6 Seamless Pipe, 6060 – T6 Aluminium Alloy butt weld pipe fitting, Al 6060 Flanges, Al 6060 Pipes kindly do contact us.

Other possible products of Aluminum:

Lr elbow , sr elbow , bend , Concentric Reducer , Eccentric Reducer , Equal Tee , Reducing Tee , End Cap etc.




If you have related inquiry , please contact us freely . We have good stock of aluminum lr elbow , aluminum sr elbow , aluminum Reducing Elbow.


108 Mm T66 ElbowEn755 2 ElbowAluminum Elbow

40AD981F2A601B910C90023D546E53C5

Aluminum elbow

AW6060 elbow


Looking for ideal 108mm Aluminum Lr Elbow Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Aluminum Elbow Stock List are quality guaranteed. We are China Origin Factory of EN755 DIN2605 Aluminum Elbow. If you have any question, please feel free to contact us.
