Shijiazhuang Bang dong Pipeline Technology Co,Ltd.
Unit Price: | USD 1.5 / Piece/Pieces |
---|---|
Payment Type: | L/C,T/T |
Incoterm: | FOB,CFR,CIF |
Min. Order: | 10 Piece/Pieces |
Model No.: butt welded elbow
Brand: Bangdong
Connection: Female
Shape: Equal
Head Code: Round
Angle: 45 Degree
Wall Thickness: Std
Material: Stainless Steel
Technics: Forged
Certification: Api
Color: Black
Packaging: Wooden Cases or as per buyer's requirements
Productivity: 1000pcs/month
Transportation: Ocean,Land,Air,s
Place of Origin: Cangzhou,China
Supply Ability: 1000pcs/month
Certificate: ISO/CE/API
HS Code: 73079300
Port: Beijing Air Port,Wuhan Train Station,Tianjin New Port
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF
Pipe Fittings butt Welded Elbow
Bangdong Supply A234 carton Steel Elbow,Socket Weld Carton Elbow,Socket Weld 90 Degree Elbow.We are manufacturer andleading supplier of buttweld fittings in all materials and forms like 90° elbow, 45° elbow, tee, cross, reducers, Pipe Cap etc.We manufacture these products in accordance with international standards and compliances.
'Manufactuer of Pipe Elbow/Bend, Long radius pipe elbows, Short radius pipe elbows, Stainless pipe elbows, Large Diameter Elbow
The degree types of long radius pipe elbows as below:
1.Product description
DN |
Outside diameter |
Center to end |
Center to center |
Back to end | |||||
45° elbow | 90°elbow | 180°elbow | 180°elbow | ||||||
A series | B series | Long radius | Long radius | Short radius | Long radius | Short radius | Long radius | Short radius | |
15 | 21.3 | 18 | 16 | 38 | - | 76 | - | 48 | - |
20 | 26.9 | 25 | 16 | 38 | - | 76 | - | 51 | - |
25 | 33.7 | 32 | 16 | 38 | 25 | 76 | 51 | 56 | 41 |
32 | 42.4 | 38 | 20 | 48 | 32 | 95 | 64 | 70 | 52 |
40 | 48.3 | 45 | 24 | 57 | 38 | 114 | 76 | 83 | 81 |
50 | 60.3 | 57 | 32 | 76 | 51 | 152 | 2 | 106 | 100 |
65 | 76.1(73) | 76 | 40 | 95 | 64 | 191 | 127 | 132 | 121 |
80 | 88.9 | 89 | 47 | 114 | 76 | 229 | 152 | 159 | 159 |
100 | 114.3 | 108 | 63 | 152 | 2 | 305 | 203 | 210 | 197 |
125 | 139.7 | 133 | 79 | 190 | 127 | 381 | 254 | 262 | 237 |
150 | 168.3 | 159 | 95 | 229 | 152 | 457 | 305 | 313 | 313 |
200 | 219.1 | 219 | 126 | 305 | 203 | 60 | 406 | 414 | 391 |
250 | 273 | 273 | 158 | 381 | 254 | 762 | 508 | 518 | 467 |
300 | 323.9 | 325 | 189 | 457 | 305 | 914 | 610 | 619 | 533 |
350 | 355.6 | 377 | 221 | 533 | 356 | 1067 | 711 | 711 | 610 |
400 | 406.4 | 426 | 253 | 610 | 406 | 1219 | 813 | 813 | 686 |
450 | 457 | 478 | 284 | 686 | 457 | 172 | 914 | 914 | 762 |
500 | 508 | 529 | 316 | 762 | 508 | 1524 | 1016 | 1016 |
2.Advantages:
1.Reasonable price with excellent quality
2.Abundant stock and prompt delivery
3.Rich supply and export experience, sincere service
4.Reliable forwarder, 2-hour away from port.
An elbow is a Pipe Fitting installed between two lengths of pipe or tubing to allow a change of direction, usually a 180° or 90° angle, though 45° elbows are also made. The ends may be machined for butt welding (SW) or socketed welding(SW) etc.
Most elbows are available in short radius or long radius variants. When the two ends differ in size, the fitting is called a Reducing Elbow or Reduced Elbow.
3. Available Materials
Stainless Steel: ASTM A403
Grade: WP 304, 304L, 304H, 316, 316L, 316Ti, 310, 347, 347H,904L etc.
Carbon Steel: ASTM A 234 WPB / A420 WPL3 / A420 WPI 6/ MSS-SP-75 WPHY 42/46/52/56/60/65/70
Alloy Steel: ASTM A 234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91 etc.
Nickel Alloys: Nickel 200 (UNS No. N02200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II)
Duplex Steel
Grade: 2205 (UNS No. S31803), 2207 (UNS No. S32760)
Product Categories : Butt Weld Pipe Fitting > Pipe Elbow/Bend
