ASME B16.5 Forged Steel Blind Flange

Share to:
    Unit Price: USD 56.97 / Piece/Pieces
    Payment Type: L/C,T/T
    Incoterm: FOB,CFR,CIF
    Min. Order: 10 Piece/Pieces

Basic Info

Model No.Blind Flanges

BrandBD

StandardGOST

TypeWelding Flange

MaterialCarbon Steel

StructureFlanges

ConnectionWelding

Sealing SurfaceFF

Manufacturing WayForging

Additional Info

PackagingWooden Case or as per buyer's requirements

Productivity100pcs/week

TransportationOcean,Land,Air

Place of OriginCangzhou,China

Supply Ability100pcs/week

CertificateCE/ISO/API

Payment TypeL/C,T/T

IncotermFOB,CFR,CIF

Product Description

Asme B16.5 Forged Steel Blind Flange


A blind flange is used to close ends of piping systems. It is a kind of round plate with no center hold but with all the proper bolt holes. This blind flange is available in various sizes and materials and is used to provide positive closer on the ends of pipes, valves or equipment nozzles. This flange helps in easy access to a line once it has been sealed. The blind flange is sometimes custom made or machined to accept a nominal sized pipe to which reduction is being made. This reduction can be a threaded reduction or welded reduction.


Stainless Steel : ASTM A 182, A 240

Grade : F304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H,904L, Duplex Stainless Steel UNS S31803, 2205, Super Duplex Stainless Steel UNS S32750

Carbon Steel : ASTM A 105, ASTM A 181

Alloy Steel : ASTM A 182, GR F1, F11, F22, F5, F9, F91

Nickel Alloys : Monel 400 & 500, Inconel 600 & 625, Incolloy 800, 825, Hastelloy C22,C276

Copper Alloys : Copper, Brass & Gunmetal

Size : 1/8" NB TO 48"NB.

Class : 150#, 300#,400 #,600#,900#, 1500# & 2500 #.

Standard

ANSI :ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48

DIN : DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673

B.S : BS4504 , BS4504, BS1560, BS10

SPECTACLE BLINDS IN BOLIER QUALTIY

SA 516 GR 70 SP. BLIND
SA 516 GR 60 SP. BLIND
SA 515 GR 70 SP. BLIND
SA 515 GR 60 SP BLIND
