NPT Threaded Swage Welding Nipple

Share to:
    Payment Type: L/C,T/T
    Incoterm: FOB,CFR,CIF
    Min. Order: 10 Piece/Pieces

Basic Info

Model No.Swage Welding Nipple

BrandBangdong

ConnectionFemale

Head CodeRound

Thread DistributionExternal Thread

SurfaceSand Blast

MaterialCarbon Steel

TechnicsForged

ApplicationWater Pipe

CustomizedCustomized

CertificationCSA

Warranty3 Years

Additional Info

PackagingWooden Cases or as per buyer's requirements

Productivity1000pcs/month

TransportationOcean,Land,Air,Train/TNT/DHL

Place of OriginCangzhou,China

Supply Ability1000pcs/month

CertificateISO/CE/API

HS Code73079300

PortTianjin New Port,Beijing Air Port,Zhengzhou Train Station

Payment TypeL/C,T/T

IncotermFOB,CFR,CIF

Product Description

NPT Threaded Swage Welding Nipple , A105 Swage Nipple

Bangdong Supply Swage Welding Nipple,Mss Sp 95 Concentric Swage Nipples,Stainless Steel Swage Nipple.These high pressure pipe fittings like threaded/Socket Elbow, steel Forged Pipe Fittings, hydraulic pipe fittings, threaded/socket tee fittings etc. are offered as per the standard specifications. Available at highly competitive prices, these fitting sand outlets can be customized as per the requirement of the client.



Swage Nipple
Swage Nipples also belong to reducer products, which are used for connecting two pipes with different diameters. The Swage Nipple has the same classification as the reducer and it can be classified into the eccentric swage nipple and the concentric swage nipple. The swage nipple generally adopts the MSS SP-95 or the BS3799 Standard.
The differences between the swage nipple and the reducer
1. Size ranges
The size range of the reducer is wide. The current size standard of the reducer is from DN15 to DN3400 (from 1/2 " to 136"), while the specification of the swage nipple is from DN6 to DN300 (from 1/4 " to 12").
2. Raw materials
Seamless Steel Pipes or steel plates are used as raw materials for reducers, while round bar steel or billet steel is selected as the raw material for Swage Nipple.
3. Manufacturing processes
The manufacturing process of the reducer is that we adopt the heat pressing process or the cold pressing process for the seamless reducer(the heat treatment is required for the cold pressing process) and we adopt the hot rolling process for the other reducer. The manufacturing process of the swage nipple is the forging process.
4. Connection ends
Beveled ends are basically adopted for reducers, and plain ends are hardly adopted for reducers. Although the plain end are allowed to be used for the stainless steel or the carbon steel reducer product whose wall thickness is lower than a certain amount. Swage nipples have more connection ends, and two ends of swage nipples can be the same or different based on the requirements of sites or designs; connection ends of swage nipples can be divided into beveled ends, plain ends and threaded ends three kinds. The following table is a good introduction to the connection end of the Swage Nipple.


Different connection ends of swage nipples

Specifications

1. When we select the swage nipple, we should mark the end. We should also mark NPT or R for taper pipe threads.

2. Big ends and small ends of swage nipples can be divided into plain ends, beveled ends and taper pipe threaded ends three kinds; the following is a table for nine combinations of big and small ends.

Type

Big End

Small End

Code

A

plain ends

plain ends

PBE

B

plain ends

beveled ends

PLE/BSE

C

plain ends

threaded ends

PLE/TSE

D

beveled ends

plain ends

BLE/PSE

E

beveled ends

beveled ends

BBE

F

beveled ends

threaded ends

BLE/TSE

G

threaded ends

plain ends

TLE/PSE

H

threaded ends

beveled ends

TLE/BSE

I

 threaded ends

threaded ends

TBE

3. Wall thicknesses of swage nipples are generally Sch80 (3000LB) or Sch160 (6000LB).


If you require any swage nipple , forged pipe fittings , forged nipple , Steel Nipple wecome to contact us freely .




Stainless Steel Forged Fitting
Standard: ASTM / ASME A/SA 182

Grade:
F 304, 304L, 304H, 309S, 309H, 310S, 310H, 316, 316TI, 316H, 316L, 316LN, 317, 317L, 321, 321H, 347, 347H, 904L.

Duplex Steel Forged Fitting & Super Duplex Forged Fittings
Standard: ASTM / ASME A/SA 182
Grade: F 44, F 45, F51, F 53, F 55, F 60, F 61.
